What is the maximum height you need to work at?

Enter the approximate height of the highest point you need to clean.

Up to 6 m

1–2 storey buildings, low roofs

Up to 9 m

2–3 storey buildings

Up to 12 m

3–4 storey buildings

Up to 16 m

4–5 storey buildings

Over 16 m

Buildings with 6 storeys or more

How many hours per week do you use the system?

Intensive use with hard water consumes a lot of resin — above a certain volume, nanofiltration or reverse osmosis can be more economical.

Less than 10 h/week

Occasional work or starting out

10 to 30 h/week

Several days per week

More than 30 h/week

Intensive daily use

Do you know the water hardness in your area?

Hard water uses more resin. If you do not know the hardness, select your country and province and we will estimate it for you.

Soft water

Below 250 ppm — north and north-west

Medium hardness

250–400 ppm — central areas

Hard water

Over 400 ppm — eastern, southern and inland areas

Very hard water

Over 550 ppm — areas with very high limescale

I do not know

Select your country and province and we will estimate it

Country Province

Estimated data based on the provincial capital. It may vary depending on your municipality.

Do you need to transport the equipment frequently?

Some systems include a trolley to make transport easier.

Few work locations

The equipment is moved infrequently or stays in the van

Routes or many work locations

I move it several times a day

HydroPower DI Calculator

What performance can you expect from a HydroPower DI with your water?

Enter your actual ppm or select your area to get an estimated guide to litres, working hours and surface area.

Guide values. The estimated ppm for an area may vary by municipality, water supply network and time of year. If you have a TDS meter, enter your actual ppm for a more accurate estimate.

Incoming water quality

ppm

Calculator range: 1–2,000 ppm.

Country

Province / district

The area value is an approximate reference, not a measurement taken at your property.

Performance is not guaranteed. Litres, hours and m² are estimates based on Unger reference data and the ppm entered. Actual performance may vary due to water composition, flow rate, resin condition and working conditions.

High resin consumption

At this ppm level, a HydroPower DI system may be uneconomical for regular use. We recommend considering a reverse osmosis system such as the Unger RO S.

View Unger RO S

Unger reference: incoming water TDS 275 ppm, output <10 ppm; laboratory values and approximate coverage. Values between reference points are calculator estimates, not an official Unger table.

Special Offer

HydroPower RO S

€3,227.57 €3,797.14 -15%

HiMod carbon

Unger nLITE Connect HiMod carbon poles

The Unger nLITE Connect HiMod poles are designed for professional pure water cleaning at great heights.

Their high-modulus carbon construction offers superior rigidity to the Carbon 24K range, helping to reduce flex and improve movement transmission to the brush as the system length increases.

High-modulus carbon with a strength of 360 GPa

The HiMod range uses a carbon material with a strength rating of 360 GPa specified by Unger.

This increased rigidity makes it easier to control the brush in long configurations, especially during frequent work at elevated heights.

HiMod UC67G main handle

The UC67G is the main telescopic handle in the nLITE Connect HiMod range.

Extended length of 6.63 metres.
Approximate folded length of 1.87 metres.
Four telescopic sections.
Approximate weight of 1.5 kg.
Round shape and maximum outside diameter of 35 mm.

It can be used on its own for medium-height work or as the main element of an extended configuration using compatible HiMod extensions.

HiMod UC35G extension

The UC35G extension allows you to increase the length of the main handle.

Extended length of 3.41 metres.
Approximate folded length of 1.91 metres.
Two telescopic sections.
Approximate weight of 0.7 kg.

Extensions must belong to the same HiMod range and be assembled according to the maximum configuration specified by Unger.

Working height of up to approximately 17 metres

Unger recommends the nLITE Connect HiMod system for working heights of up to approximately 17 metres.

The actual achievable height depends on the number of authorised extensions, the operator’s height, the pole angle, the position of the glass and the accessories fitted.

nLITE Connect modular system

The system consists of a main handle and compatible telescopic extensions. This allows the length to be adapted to each job without always using the full configuration.

The components maintain a maximum outside diameter of 35 mm to prevent the grip area from becoming excessively large when extensions are added.

nLITE Connect angle adapter

The nLITE Connect angle adapter allows the brush to be connected and positioned in relation to the pole.

Its modular system has various combinable components and uses the FastLock connection to secure the brush. It is designed for nLITE Connect round aluminium, HiMod and Ultra HiMod handles.

External hose routing

In the nLITE Connect HiMod range, the hose is routed along the outside of the pole using compatible fastening components.

Before connecting the system, check the hose diameter, the connections on the pure water equipment and the accessories fitted to the brush.

When should you choose HiMod?

For frequent professional work at great heights.
When more rigidity is needed than with Carbon 24K.
For working configurations of up to approximately 17 metres.
When a modular system with a main handle and extensions is preferred.

For lower heights, Carbon 24K poles may be sufficient. For configurations of up to approximately 20 metres, see the Ultra HiMod range.

If you need help calculating the right configuration, you can call us on 627 588 844.

Show Less

Sort by:

View

There are 3 products.

HiFlo nLITE HiMod Carbon Master Pole

Unger HiFlo nLITE HiMod carbon master pole for pure water window cleaning at great heights. 6.63 metres extended, 1.87 metres collapsed, 4 sections and 1.5 kg. 360 GPa stiffness — 70% more than 24K carbon. Extendable up to 20 metres by adding up to 4 UC35G extensions. Compatible with nLITE brushes. Angle adapter and accessories not included.

€1,119.89

Mango de extensión HiFlo nLite HIMOD CARBONO

HiFlo nLITE HiMod Carbon Extension Pole

Unger HiFlo nLITE HiMod carbon extension for extending the reach of the UC67G master pole. 3.41 metres when extended, 1.91 metres when collapsed, 2 sections, 360 GPa of stiffness and weighing just 0.7 kg. Up to 4 UC35G extensions can be connected to reach a total of 20 metres. Yellow warning zone helps prevent unintentional separation. Compatible with the UC67G master pole and other UC35G extensions.

€601.00

nLITE Connect Angle Adapter

Unger nLITE Connect Angle Adapter for connecting the pure water brush to the telescopic pole. Available in three lengths: 15 cm, 42 cm and 82 cm. FastLock system for changing the brush in seconds and adjusting the angle in 45° increments without twisting during cleaning. Compatible with nLITE Connect poles and Power nLITE brushes. Brush not included.

€25.19

Details View details

HiMod compared with Carbon 24K and Ultra HiMod

The HiMod range occupies an intermediate position between Carbon 24K and Ultra HiMod:

Compared with Carbon 24K: it offers greater rigidity and is designed for higher configurations.
Compared with Ultra HiMod: it has lower rigidity and a lower recommended maximum height, but allows work up to approximately 17 metres.

Compatibility with pure water systems

HiMod poles can be connected to DI filters, HydroPower Nano equipment and reverse osmosis systems using the appropriate hoses, valves and connections.

Before connecting the pole, check the coupling type, the hose diameter and the accessories included with the filtration equipment.

High Rise kits with HiMod pole

Some pure water kits for great heights include a HiMod main handle, extensions, brush, hose and filtration equipment.

The contents vary depending on the kit. Check each product page to confirm the configured length and included components.

Safe use at great heights

Before starting, check the locking of each section, the connections between the main handle and extensions, the hose, the angle adapter and the brush attachment.

Do not exceed the maximum configuration specified by Unger. Maintain a safe distance from power lines, wiring and other obstacles, as carbon poles conduct electricity.

Unger distributors and Technical Service

As official Unger distributors and Technical Service in Spain, we offer advice on calculating the height, selecting extensions and finding compatible brushes, hoses and connections.
